Our Approach: How We Take A Job From Drawing To Delivery
Introduction
Every component we machine follows the same disciplined process, whether it's a single prototype or a full production run. For engineers and buyers evaluating a new CNC machining partner, understanding that process matters as much as the equipment on the shop floor — it's what determines whether a job arrives on time, to spec, and with the paperwork to prove it. Here's how a job moves through Evo Precision Engineering, from the first drawing to the finished part on your dock.
1. Drawing Review & Design for Manufacture (DFM)
Every job starts with your technical drawing or CAD file. Before any machining is quoted, we review it for manufacturability - checking tolerances, material choice, and geometry against what's actually achievable and cost-effective on our equipment. This is where design for manufacture (DFM) feedback happens: if a feature is difficult or expensive to machine as drawn, we'll flag it and suggest an alternative before you commit to a production run, not after.
2. Quoting
Once we understand the part, we put together a quote that reflects the real process — machine time, tooling, material, and finishing - rather than a generic estimate. If your drawing needs multiple processes (turning, milling, and assembly, for example), the quote accounts for the full job, not just one operation.
3. Programming & Machining
Our CNC turning and milling centres - including 3 & 5-axis capability with live tooling — are programmed specifically for your part. Whether it's a single prototype to validate a design or a production batch, the same programming discipline applies: first-off inspection before a full run starts, so problems get caught on part one, not part fifty.
4. Inspection & Traceability
Every job is inspected against the drawing before it leaves our facility. Our quality management system is ISO 9001:2015 certified, and material traceability follows EN 10204 3.1 where required - meaning the certificate you receive with your parts can be traced back to the raw material batch it came from. For regulated industries especially, that traceability isn't a nice-to-have, it's the difference between a usable part and a rejected one.
5. Assembly & Finishing
For jobs that need it, we handle assembly in-house - turning individual machined components into a complete, ready-to-use sub-assembly rather than handing you a box of parts to put together yourself.
6. Delivery
The finished job is packaged and delivered along with full inspection documentation and material certification. From our facility in Tuam, Co. Galway, we work with clients across Ireland and beyond.
Why This Process Matters:
A lot of what separates a reliable machining partner from a risky one happens before the first cut is made — in the drawing review and quoting stage — and after the last cut, in inspection. Skipping either step is how components end up late, out of tolerance, or without the paperwork a regulated buyer needs. Building both into every job, regardless of size, is what this process is designed to protect.
Ready to Start Your Project?
Send us your drawing and we'll walk you through the same process — from initial review to a finished, inspected part. ISO 9001:2015 certified, based in Tuam, Co. Galway.
